Teknik Özellikler |
Performance Specification |
Processor |
TI AM3715，1GHz |
Operating System |
Microsoft Window CE 6.0 R3 |
Memory , Flash |
nand flash 4Gb（256Mb*16）=512MB |
mobile DDR 2Gb（64Mb*32）=256MB |
Fiscal memory |
Standart 2GB to MAX 32GB |
Display Resolution |
3.5 inch 240 × 320 Pixels / 262,000 Color |
Display Back |
7mm Font Color LCD |
Interface |
1 USB （OTG type，Host port，Client port），1 USB（RS232port）, 1 Ethernet ( Opsionel ) |
Expansion Slot |
Mini SD Card Slot |
Audio |
Speaker (mono) x 1, Microphone x 1, |
Vibration |
yes |
Key Specification |
Alpha & numeric Keys, Navigation Key (Total 20 hardware Keys ) |
PCI |
PCI 3.0 Online/ Offline |
Smart Card |
EMV L1&L2 Certified Smart Card Reader, 2 SAMs slot |
Magnetic Card Reader |
Triple Track (track 1, 2, & 3) |
Printer |
High Speed, High resolution, thermal printer |
Printer Paper |
Diameter=30mm, width=58mm |
OPTION |
Camera / Kare Barkod |
3.1 M Pixel |
Scanner |
1D /2D |
RFID |
Mifare A/B Type,qPBOC,Contactless EMV |
GPS |
SiRFstarIII GSC3e/LP |
WIFI |
802.11 b/g/n |
Bluetooth |
BT Class2.0-EDR |
Power |
2000mAh Li-ion Removable / Rechargeable Battery |
Communication Interface (built-in) |
GSM/GPRS/EDGE /CDMA/3G Modem, 1 USIM slot. |
Physical Specification |
Weight |
500g |
Operating Temperature |
-20°C to 50°C |
Accessories |
Default |
User's Manual, USB Cable, Stylus Pen, |
Other |
AC adapter, Ear-Micphone (Mono) , Cradle (option) |
Secure Performance Specification |
Processor |
MAXQ1850 |
Operating System |
VOS |
Memory , Flash |
Share Flash |
Interface |
UART |
